Page 11
Page
Pos.
LT
-210
LT
-250
Part No.
Notes
Description
Specifications
5
18
1
388 101 100
CRANKCASE CPL.
INCL. FIG. 19, 107 & 108
5
19
1
388 150 220
CRANKCASE GASKET
5
20
1
367 201 100
CRANKSHAFT CPL.
INCL. FIG. 78
5
21
1
388 250 190
PISTON
5
22
1
382 250 070
PISTON RING
5
23
1
388 250 260
PISTON PIN
5
24
2
388 508 997
CLIP
5
25
1
388 150 230
CYLINDER GASKET
5
26
1
388 150 180
CYLINDER
5
27
2
374 005 970
SCREW ASS'Y
M5X20
5
28
2
388 350 390
INSULATOR GASKET
5
29
1
388 350 400
CARBURETOR INSULATOR
5
30
1
388 303 800
INSULATOR CPL.
5
31
1
388 350 410
INSULATOR GASKET
5
32
2
388 005 950
SCREW
M5X25
5
33
1
388 550 120
WIRE
5
34
1
388 350 430
MUFFLER GASKET
5
35
1
388 350 440
MUFFLER INSULATOR
5
36
1
388 303 700
EXHAUST MUFFLER
5
37
2
381 100 500
WASHER
M5
5
38
2
388 905 960
S. H. BOLT
M5X45
5
39
1
388 703 101
FLYWHEEL
5
40
1
388 703 102
COIL
5
41
2
367 004 992
SCREW ASS'Y
M4X20
5
42
1
388 750 320
GROMMET
5
43
1
377 400 993
PLUG CAP SPRING
5
44
1
388 750 330
PLUG CAP
5
45
1
381 014 981
SPARK PLUG
5
46
1
388 200 500
CLUTCH ASS'Y
5
47
1
388 200 400
CLUTCH DRUM CPL.
5
48
1
381 503 500
ENGINE COVER CPL.
5
49
1
374 151 000
OUTER SNAP RING
10
5
50
3
374 005 970
SCREW ASS'Y
M5X20
5
51
1
388 500 300
PULLEY
5
52
1
388 550 470
BOLT ASS'Y
5
53
1
388 503 300
STARTER COVER CPL.
INCL. FIG. 51, 102-106
5
54
1
388 650 430
PUMP
5
55
4
374 005 945
SCREW
M5X18
5
56
1
388 650 410
FUEL TANK
5
57
1
388 600 200
FUEL TANK CAP ASS'Y
5
58
1
388 604 800
TUBE
5
59
1
382 650 390
FILTER
5
60
1
381 650 030
PLATE
5
61
1
381 650 020
PLATE
5
62
2
381 650 025
DAMPER
5
63
2
388 360 530
SCREW ASS'Y
5
64
2
381 270 500
NUT
M5
5
65
1
388 005 995
TAPPING SCREW
M5X8
5
66
1
388 550 460
TAPPING SCREW
5
78
1
388 250 240
STUD
5
102
1
381 500 202
REEL
5
103
1
381 500 203
SPIRAL SPRING
5
104
1
381 500 206
STARTER ROPE
5
105
1
388 500 402
HANDLE CPL.
5
106
1
388 500 301
SET SCREW
5
107
1
388 012 997
OIL SEAL
5
108
1
388 012 997
OIL SEAL
LT-250
