6
1. Keep the heater closed position and lay the
unit down on the stable table spread the soft
cloth. (Fig. 1)
2. Assemble the frames to the legs and attach
the frame supports on right and left side.
(Fig. 2)
3. Fix the frame and frame support with Wing
nut tightly. (Fig. 3)
4 Turn the heater upside
down and assemble the
frame to the legs with
Wing nut the same way as
the above. (Fig. 1-3)
Do not insert the plug in electrical outlet before completing
assembling.
5. Set up the heater carefully and be sure that the frames are fixed firmly.
Frame
Frame
support
(Fig. 2)
(Fig. 3)
(Fig. 1)
Wing nut
Soft cloth
CAUTION
HOW TO ASSEMBLE THE FRAME
)
