15
Models 2E510F, 2E511F, 3E218E, and 3E219E
Dayton Operating Instructions and Parts Manual
105553
®
1 Handle M51104-01 1 1
2 Upper Shell 098511-34 1 1
3 #10-16 x 3/4" Screw * M11084-29 2 2
4 #10-16 x 1/2" Screw * 100647-01 6 6
5 Combustion Chamber 098512-58 1 —
098512-50 — 1
6 #6-32 x 3/8" Screw * M10908-2 2 2
7 Photocell Bracket 103154-03 1 1
8 Photocell Assembly M16656-23 1 1
9 Burner Assembly † 1 1
10 #10-16 x 3/8" Screw * M11084-26 2 2
11 Fan 103684-01 1 1
12 Motor and Pump Assembly † 1 1
13 Fan Guard M51105-01 1 1
14 Power Cord 098219-31 1 1
15 Strain Relief Bushing M11143-1 1 1
16 1/4-20 Hex Lock Nut NTC-4C 2 2
17 #10-16 x 3/8" Screw * M11084-26 4 4
18 Rubber Bumper M50631 2 2
19 Side Cover 097461-03AA 1 1
20 Motor Bracket 101205-01 1 1
21 Bushing M30865-02 2 2
22 Clip Nut M11271-8 6 6
23 Bushing M50104-02 1 1
24 #10-16 x 3/8" Screw * M11084-26 6 6
25 #8-32 x 3/8" Screw * M10908-14 1 1
26 Lower Shell 098511-14 1 1
27 Rubber Airline M50814-06 1 1
28 Fuel Line 079973-01 1 1
29 Fuel Filter (with Bushing) M50876-04 1 —
M50876-05 — 1
30 Rubber Bushing M10990-3 1 1
31 Button Plug 101695-01 1 1
32 PCB Support 102349-01 5 5
33 Ignition Control Assembly 104068-03 1 1
34 Fuel Cap (Includes Gasket) 097702-01 1 1
35 Fuel Tank 098513-23 1 —
098513-62 — 1
36 Shell Heat Shield M51108-01 1 1
∆ Wire Tie 103814-01 1 1
Ref. Part 2E510F 2E511F
No. Description Number Qty. Qty.
Ref. Part 2E510F 2E511F
No. Description Number Qty. Qty.
(*) Standard hardware item, available locally.
( ∆ ) Not shown.
(†) Not available as an assembly, see page 13.
Replacement Parts List for Models 2E510F and 2E511F
