Dayton 5S1792 - Manual

Operating Instructions & Parts Manual
Dayton Portable
Oil-Fired Heaters
®
Form 5S1792
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Unpacking
1. Remove all packing items supplied
with heater for shipment.
2. Remove all items from carton.
3. Check heater for any shipping
damage. If heater is damaged,
promptly inform dealer where you
bought heater.
2E510F, 2E511F, 3E218E, and 3E219E
Version B - For Reduction G016.J
®
Figure 1 – Models 2E510F and 2E511F Figure 2 – Models 3E218E and 3E219E
Description
Dayton Models 2E510F, 2E511F, 3E218E, and 3E219E are 40,000 to 155,000 Btu/Hr
heaters. These heaters use only Kerosene or No. 1 fuel oil for combustion and
electricity to run the motor. They are primarily intended for indoor and outdoor
temporary heating of well-ventilated buildings under construction, alteration, or
repair. They may be used in agricultural, industrial, and commercial environments.
Output Fuel Tank Capacity Fuel Consumption
Model Rating Btu Fuel (U.S. Gallons) (U.S. Gallons/Hr.) Motor RPM
2E510F 40,000 Kerosene or No. 1 fuel oil 3.0 0.3 1725
2E511F 60,000 Kerosene or No. 1 fuel oil 5.0 0.44 1725
3E218E 110,000 Kerosene or No. 1 fuel oil 9.0 0.8 3450
3E219E 155,000 Kerosene or No. 1 fuel oil 13.5 1.14 3450
Hot Air Air Pump Shipping Weight Heater Weight
Model Output (CFM) Pressure (psi) (Pounds) (Pounds - without fuel)
2E510F 170 3.0 32 28
2E511F 180 3.4 33 29
3E218E 490 5.3 58 49
3E219E 550 5.4 67 56
GENERAL SPECIFICATIONS
Printed in U.S.A.
03430
0899/29 5/VCPVP
Specifications
®
