Televes Avant 7, 6 In/1 Out FM-BIII/DAB-TB-U-U-U (790 MHz) - Manual (Page 17)

EN
17
Typical application
532840 532940
532970
UHF1 UHF1
UHF2 UHF2
FM (1) FM (1)
FI (2)
MATV + FI (2)
MATV
MATV
TEST
Note:
All levels entered through
the broadband input
(47-862 MHz) should be
adjusted between 69 - 73
dBµV for VHF channels and
between 70 - 74 dBµV for
UHF channels, thus these
channels are adjusted
to the same level as the
selected filters.
196-264V~
50/60 Hz
196-264V~
50/60 Hz
(1) 532970 => BI/FM
(2) Available in ref. 532840
Ref. 4061 Ref. 4061
Ref. 4061
Ref. 543603
Adjust
532840
Ref. 5363
UHF1
UHF2
UHF3
FM (1)
FI 1 (2)
BIII/DAB
196-264V~
50/60 Hz
70...74dBμV
(UHF)
FI 2
MATV + FI 2
MATV + FI 1 (2)
MATV
7 x QPSK - PAL
Ref. 5537xx
7 x DVB-S2 - COFDM
Ref. 5631xx
