FO-065-1185 Media Converter Chassis System
User’s Manual 7
Deciding How to Install the System
We strongly suggest that you install the chassis first, as this is more
convenient for you to install media converters into the chassis with
ease. The accessories supplied in the product package includes:
rackmount screws, rackmount brackets, and bracket screws.
This well-built chassis can be installed in the following ways:
M
OUNTED TO
19-
INCH STANDARD RACK
Use the rackmount brackets and screws to install the chassis into
any EIA 19” standard rack.
Step 1:
Attach the brackets to each side of the chassis. Apply screws to
each side and secure them tightly.
Step 2: Carefully position the chassis into the rack. Align the brackets to
the side holes on the rack and use rack screws to secure the
chassis with the rack.
Step 3: Proceed to the “Connecting to Power” section.
D
ESKTOP OR ANY FLAT SURFACE
The chassis can sit on desktop or any flat surface with adequate
space and ventilation. If you want to place it onto a shelf, make
sure the shelf can withstand a minimum weight of 10kg.
Step 1:
Simply put the chassis on the desired place.
Step 2:
Ensure the chassis receives good ventilation.
Step 3:
Proceed to the “Connecting to Power” section.
