FO-065-1185 Media Converter Chassis System
8 User’s Manual
Installing Media Converter
The chassis is equipped with media converter carriers, each of
which is fitted into bays of the chassis.
Step 1:
To install a media converter onto any of the carriers, you have to
unscrew the carrier from the desired bay first.
Step 2: Fit the media converter onto the carrier.
Step 3:
When the media converter is completely seated onto the carrier,
insert the carrier to the guide rails of the bay slot.
Step 4:
Carefully slide in the carrier until it is fully and firmly fitted to the
power socket. Fasten the screws on the carrier.
i
i. The chassis is designed to house only the proprietary media converters.
ii. Never insert any media converter into the chas sis directly without using
the supplied carriers. These carriers allow secure and consistent
placement of the media converters into the chassis’ backplane without
causing any damage.
iii. For details, please refer to the User’s Manual for media converters.
