A-12
P/N: 4809621
©2003 Paxton Automotive
All Rights Reserved, Intl. Copr. Secured
18SEP03 v1.0 Dodge Ram 1500(4809621v1.0)
Appendix 11
1020215
Asy
, Coil Relocation
✒
NOTES: UNLESS OTHERWISE SPECIFIED 1. THESE ITEMS SHIP LOOSE.
1
TO MTG STUD
TO COIL
2X
2
3
ITEM NO.
QTY
.
P
AR
T NO.
DESCRIPTION
1 2 3 4 5 6 7
1 2 2
.8 FT .8 FT
4
.7 FT
4PCD010-040
7J250-001 7A250-101 5W018-020 5W018-070 5W001-012 5W001-032
BRKT
, COIL RELOCA
TE
W
ASHER, FLA
T 1/4
SCREW
, 1/4-20 x 1.00 LG
WIRE, 18A
WG BLACK x 9" LG
WIRE, 18A
WG GREEN x 9" LG
CONN, BUTT 22-18 GA TUBING SPLIT POL
Y LOOM
1 1 1 1
SCALE:
SIZE
DWG. NO.
B
SHEET
1
O
F
1
REV
.
DA
TE
APPROV
ALS
DRA
WN
ENGINEERING R&D
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE:
DECIMALS:
.XX
± .01
.XXX
± .005
MA
TERIAL
FINISH
NONE
SEE P
A
R
TS LIST
DO NOT SCALE DRA
WING
WEIGHT
0.2 LBS
1:1
1020215
A
FRACTIONS:
ANGLES:
± 1/16 ± 1/2•
ASY
, COIL RELOCA
TION
APPR.
G. COMPTON
9/11/00
2002 DODGE RAM 5.9L
A. PROCTOR G. COMPTON
10/4/01 10/6/01
1300 BEACON PLACE OXNARD, CA 93033 TEL: (805) 604-1336 F
AX: (805) 604-1337
CAD GENERA
T
ED DRA
WING,
DO NOT MANUALL
Y UPDA
TE
L. KECK
10/6/01
