2 Installation
2.1 Package Contents
• One
FDVA2-M2T-WSC
Transmitter
• One FDVA2-M2R-WSC Receiver
• Two power supply adaptors
• Two
User
Manuals
Please contact dealer or distributor if part is missing or damaged.
2.2 Transmitter Enclosure
Transmitter Top View
LEDs Definition:
POW:
Power Supply.
On if power input is in OK.
Transmitter Right View
Connectors:
VIDEO 1: Channel 1 Video BNC, input
POWER
VIDEO1
FIB1
12~24V
FIB2
VIDEO2
VIDEO 2 VIDEO 1
+
-
