the Packer. (See step 5 on page 13 for definition.)

Matrix ES into standard surround channels

– (read-only flag) specifies

mixing of Center Surround into Left and Right Surround. This is dependent
on the channel configuration selected when packing, and is only relevant for
ES encodings.

Phase shift

ES channels – Works only with ES source files, where it allows

for phase shifting of Left and Right Surround by ±45° prior to addition of
Center Surround channel.

Note:

DTS strongly recommends Phase shift be set ON during 6.1 ES

encoding for film. For music, you may wish to experiment with both settings.

For more information, see the topic

DVD Authoring for DTS

on page 28.

If you want to erase the changes you have made and start over, click Reset
defaults.

This will reload the values from the packed source file.

5.

Click the

Print

button to print the form before submitting it.

Click the

Submit Job

button to schedule the job for encoding.

All fields are checked for validity before the job is added to the database. A
confirmation screen will display, prompting you to review the encoder settings
and confirm.

Manager and User Guide –

DTS Pro Series Network Encoder for MAC OSX

If unchecked, both the

Output start time

and

Output end time

are

editable. Use output start and end times if you want to encode a portion (not
all) of the source file. For example, this is where you would trim the pre-roll
and post-roll of the project.

The Frame rate cannot be edited (it is read-only). It simple provides
information for the user about the packed file.

4.

Format

and

Bitrate

fields are selectable based on the choice of source file.

For 44.1 kHz and 88.2 kHz source files, only one bit rate (1234800) and
output type (.wav) are possible.

With 48 kHz source files for DVD encoding,

Bit rate

is selectable: 1509750

bits (1.5 Mbps) or 754500 (754 kbps). With 96 kHz files, only 1.5 Mbps bit
rate is possible.

With 48 and 96 kHz source files, Format is also selectable:

DTS wave format .wav (Intel byte order, wav header)

DTS padded format .dts (raw file, no wave header, Motorola format, and zero
padding to fill frames)

DTS compacted format .cpt (Motorola byte order, zero padding is removed,
timecode is removed but a start time is present). This is the output type
needed for the Apple DVD Studio Pro V3.0.

The .wav format is used for music where there is no picture to lock to. Wav is
typically for 5.1 or 6.1 music surround discs. The .cpt and .dts formats are
used in DVD authoring. Please refer to the topic

DVD Authoring for DTS

on

page 28 to determine the correct bitstream to use. Typically, a .cpt file is
used, because the .DTS format is a padded file that is used in older DVD
authoring systems.

Dialog Normalization,

click the arrows to change the setting, if necessary.

For more information, see

Dialog Normalization,

page 29.

Attenuate rear channels 3 dB

is display-only here. This parameter is set in

DTS Pro Series Network Encoder for MAC OSX

– Manager and User Guide
