PARTS LIST
Models (V)K36N, (V)K36NH, (V)K36P, (V)K36PH
PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 31 of this manual.
REFRACTORY BRICK PANELS
K36N VK36N K36NH VK36NH
K36P VK36P K36PH VK36PH DESCRIPTION QTY
110989-02 110989-01 111215-02 111215-01 Left Refractory Brick Panel 1
110991-02 110991-01 111217-02 111217-01 Rear Refractory Brick Panel 1
110990-02 110990-01 111216-02 111216-01 Right Refractory Brick Panel 1
** Part not available for field replacement.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 ** Firebox Assembly 1
2 ** Face Weldment 1
3 108010-01 Door Assembly 1
108010-02 Door Assembly (V Models Only) 1
4 108011-01 Top Louver Assembly 1
5 108011-02 Bottom Louver Assembly 1
6 ** Fireplace Top 1
7 ** Fireplace Top Insulation 1
8 ** Fireplace Surround 1
9 109082-01 Heat Shield 1
10 111958-01 Log Set 1
10-1 111933-01 Left Base Log 1
10-2 111932-01 Right Base Log 1
10-3 111961-01 Left Front Log 1
10-4 111960-01 Right Front Log 1
10-5 111926-01 Right Rear Log 1
10-6 111929-01 Middle Crossover Log 1
10-7 111959-01 Left Rear Log 1
10-8 111930-01 Left Crossover Log 1
10-9 111962-01 Right Crossover Log 1
11 See Below Left Refractory Brick Panel 1
12 See Below Rear Refractory Brick Panel 1
13 See Below Right Refractory Brick Panel 1
14 108719-01 Screen Rod 1
15 12105 Screen 2
16 11418 Push-On Nut 2
17 14123 Strain Relief 1
18 21171 Gas Knock-Out Cover 2
19 24353 Handy Box Assembly 1
20 24460 Gas Conduit Assembly 1
21 111956-01 Burner Assembly (Natural Gas)(See pages 34 and 35) 1
111956-02 Burner Assembly (Propane/LP Gas) 1
PARTS AVAILABLE - NOT SHOWN
25487 Lava Rock/Bag Assy 1
27253 Notice Label 1
55240 Vent Label 1
