COMMELL MPX-24794S User Manual
Page 28
MPX-24794S User’s Guide
Ver 1.10
Taiwan Commate Computer Inc.
23
Figure 16 ADP-GPION4I4O5V
Use either P1 and/or P2 connector (2x6 header) of OAL-24794S-ADP cable to
connect to one or two of this board.
2.4.2 ADP-GPION8I5V (option)
ADP-GPION8I5V is a signaling isolation board for Commell GPIO products. This
board has eight photo-couple input connectors. Eight photo-couple diodes protect
input lines from the damage caused by ElectroStatic Discharge (ESD) and other
transients.
Figure 17 ADP-GPION8I5V
Use either P1 and/or P2 connector (2x6 header) of OAL-24794S-ADP cable to
connect to one or two of this board.
