COMMELL MPX-24794S User Manual
Page 21
MPX-24794S User’s Guide
Ver 1.10
Taiwan Commate Computer Inc.
16
Connect the P2 to the CN_USB port of the MPX-24749S card. OALUSB-H4-1 cable
is convenient for your development stage.
2.2.4 OALUSB-H4 cable (option)
OALUSB-H4 cable is another alternate cable to connect the MPX-24794S card to one
of the USB 2.0 pin header on your motherboard.
The following figure shows the cable description.
Figure 11 OALUSB-H4 cable
Connecting the P2 to the CN_USB port of the MPX-24749S card meanwhile
connecting P1 to a USB 2.0 pin header of your target motherboard.
2.2.5 OAL-24794S-ADP Cable (option)
This cable is specific designed to connect MPX-24794S board to ADP-
GPION4I4O5V and ADP-GPION8I5V Commell GPIO signaling isolation boards.
This cable is optional to the MXP-24794S card. The following figure shows the
drawing of this cable.
