MS-C71 User’s Manual
-
17
-
2.6
Based on Intel QM57, the board provides Six Serial ATAII interfaces SATA1 to SATA6
with up to 300MB/s transfer rate and VIA 6421 two Serial ATAI interfaces SATA7 and
SATA8 with 150MB/s of transfer rate.
2.6.1 IDE interface & CF interface
The MS-C71 has VIA 6421 chip supports one 40-pin IDE connector, dual channel for
two ATAPI devices with ATA100 and one CompactFlash Type II socket.
SATA Port 1/2/3/4/5/6
SATA Port 7/8
IDE
CF
