DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

SMT Power Inductor

SIL620 Type

RoHS compliant.
Small size (5.6mm*5.6mm), Low profile (2.0mm max. height) SMD type.
Magnetically shielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.

Features

37

0.

00

0.01

0.10

1.00

10.00

CURRENT (A)

10.00

100.00

IN

D

U

C

T

A

N

C

E

(u

H

)

5R4

6R2

8R2

100

120

150

180

220

270

330

390

470

560

680

820

101

4R1

4R1

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com

o

25 C: 100KHz, 0.1V

Electrical Characteristics:

SIL620 - 1R1

1.1

0.030

3.70

SIL620 - 1R5

1.5

0.040

3.00

SIL620 - 2R5

2.5

0.048

2.50

SIL620 - 3R3

3.3

0.054

2.10

SIL620 - 4R1

4.1

0.057

1.95

SIL620 - 4R7

4.7

0.080

1.70

SIL620 - 6R0

6.0

0.100

1.50

SIL620 - 6R8

6.8

0.110

1.40

SIL620 - 8R9

8.9

0.140

1.25

SIL620 - 100

10.0

0.160

1.20

SIL620 - 120

12.0

0.215

1.10

SIL620 - 150

15.0

0.224

0.97

SIL620 - 180

18.0

0.247

0.85

SIL620 - 220

22.0

0.290

0.80

SIL620 - 270

27.0

0.330

0.75

SIL620 - 330

33.0

0.386

0.65

SIL620 - 390

39.0

0.520

0.57

SIL620 - 470

47.0

0.595

0.54

SIL620 - 560

56.0

0.665

0.50

SIL620 - 680

68.0

0.840

0.43

SIL620 - 820

82.0

0.978

0.41

SIL620 - 101

100.0

1.200

0.36

2

Irated

(Adc)

PART NO.

DCR

( ) MAX

1

L

(uH)

1. Tolerance of inductance : 3

0%.

2. Irated is the DC current which cause the inductance drop less than 35% of its nominal inductance without current

o

and the surface temperature of the part increase less than 45 C.

o

o

3. Operating temperature: -20 C to 105 C (including self-temperature rise).

Mechanical Dimension:

6.3

1.5

C

D

B

A

6.3

UNIT:mm/inch

C = 2.0 / 0.079 Max.

UNIT:mm/inch
A = 6.0 / 0.236 Max.
B = 6.0 / 0.236 Max.

D = 2.0 0.1 / 0.079 0.004

2

1

RECOMMENDED PAD PATTERNS
