Dimplex Duo400i - Manual (Page 3)

Two Zone Wall Mounted Programmer
(only applicable if Programmer is fitted to DuoHeat installation)
The programmer has two modes (i) AUTO or (ii) MANUAL
(i) In “Auto” mode, the radiator will change between Comfort and Setback modes (as shown in the table below) depending
on your seven day programme. To change the programme settings or temporarily over ride the programme, see the
appropriate programmer instructions.
(ii) “Manual” mode will override the auto programme setting. There are four “Manual” mode settings shown in the table below.
RX010006 - Pilot Wire, or
RX010007 - Mains Borne Signalling
H
J
Note: It will take 24 hours for room temperature to reach a comfortable level when resetting
from “Setback”, “Frost Protect”, “Off” to “Comfort”.
Everyday Operation
Once the Background level has been set (see Achieving
Optimum Comfort Level above), this should not require any
further adjustment.
Adjust the Comfort setting as required to suit your comfort needs
and occupancy pattern. For a short period of non occupancy
the control can be lowered slightly (we recommend by no more
than 2 bars) to save energy when the room is unoccupied and
increased again when more heat is needed.
Non Occupancy (vacant)
For long periods of non occupancy, reduce the Background
and the Comfort to their lowest settings.
It will take 24 hours for room temperature to reach a
comfortable level when resetting from Low settings to
Normal settings.
Child Lock Operation
To activate the child lock simultaneously depress the
+
and
-
buttons for a period of 3 seconds. After this period the child lock
is in operation and the LED will illuminate for short period and
then revert to the setback setting. The LED beside the key symbol
will illuminate while the child lock is in operation.
Once in the locked position, if either of the controls are operated
the LED will resume maximum illumination for a short period before
reverting back to the setback position.
To deactivate the child lock, depress the buttons simultaneously
again for 3 seconds and the buttons will become active.
Safety - Overheat Protection
For your safety, this appliance is fitted with thermal cut-outs. In
the event that the product overheats, the cut-outs switch the
radiator off automatically. In the event of these safety cut-outs
activating please inform the installer or Dimplex Customer Services
for advice in order to reset the cut-outs.
Programmer Mode Temperature Setting DuoHeat Radiator –
“Temperature control display setting”
Comfort Setting (radiator setting). Each
Comfort Radiator will operate as set in “controls” Display will remain as shown in Quick Start Guide
section of Operating Instructions.
Setback will reduce the Comfort setting by Display will show two red bars less.eg. if “Comfort”
Setback 2°C, and will leave the Background displays 5, “Setback” will display 3 red bars.
unaffected.
Frost Protect Room temperature will be maintained at Display will show one red bar.
16°C with Background operating.
This will completely switch off radiators,
Off e.g. during the summer heating may not be Display will show one red bar.
required.
