Setting items

Setting contents

Channel Level

Set the volume of the test
tone to be the same when it
is output from each speaker.

Test Tone Start : Output test tones.

FL (Front L)/ C (Center)/ FR (Front R)/ SR (Surround R)/
SBRz (Surround Back R)/ SBLz (Surround Back L)/ SL (Surround L)/
FHL (Front Height L)/ FHR (Front Height R)/ SW (Subwoofer) : Select
the speaker.

z

When the “S.Back” setting (vpage 25) is set to “1ch”, “SB” is
displayed.

–12.0dB ~ +12.0dB (0.0dB) : Adjust the volume.

• When “Channel Level” is adjusted, the adjusted values are set for

all the surround modes. To adjust the channel level separately for the
different surround modes, use the operation see “Adjust the volume of
the different speakers” (vpage 45).

• Speakers set to “None” in the “Speaker Config.” (vpage 25) settings

are not displayed.

• When o is pressed while the subwoofer volume is set to “–12dB”, the

“Channel Level” setting switches to “OFF”.

If output of the test tones begins while the muting mode is set, the
muting mode is canceled.

Default : Reset all channel level settings to factory default.

Yes : Reset to the defaults.
No : Do not reset to the defaults.

Crossover Frequency

Outputs at below set
frequency, each speaker’s
bass signal output from the
subwoofer. Set this according
to the low frequency
reproduction capabilities of
the speakers you are using.

This can be set when
“Speaker Config.” –
“Subwoofer” (vpage
25) is set to “Yes” or
“No”.

Crossover :

Outputs at below set frequency, each speaker’s bass signal

output from the subwoofer.

40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /
250Hz
Advanced :
Set the low frequency signals to be output from the signals
of the respective speakers to the subwoofer.

Front / Center / Surround / S.Back / Front Height :

Select the speaker.

· 40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /

250Hz : Set the crossover frequency.

Setting items

Setting contents

Crossover Frequency

• Always set the crossover frequency to “80 Hz”. When using small

speakers, however, we recommend setting the crossover frequency
to a higher frequency.

• For speakers set to “Small”, sound below the crossover frequency

is cut from the sound output. The cut bass sound is output from the
subwoofer or front speakers.

The speakers that can be set when “Advanced” is selected differ
according to the “Bass Setting” setting (vpage 25).

· When “LFE” is selected, speakers set to “Small” at “Speaker

Config.” (vpage 25) can be set.

· When “LFE+Main” is selected, speakers can be set regardless of

the speaker size setting.

Making detailed settings (Manual Setup)

: Moves the cursor (Up/Down/Left/Right)

: Decision the setting

: Return to previous menu

Remote control

operation buttons

:

Displaying the menu

Cancel the menu
