20
Specification
Specifications are subject to change without notice. Mass and dimension are
approximate.
General
Power supply:
12 V DC
Current consumption max. 15 A
Maximum power output: 50Wx4 channels
Fuse: 15A
Dimensions (W x H x D) 178 x 50 x 192 mm
FM Stereo Radio. Frequency range: 87.5 - 108.0 MHz
Usable sensitivity: 3 uV
I.F. Frequency: 10.7 MHz
MW Section
Frequency range:
522 kHz-1620 kHz
Usable sensitivity: 40 dB
I.F. Frequency: 450 kHz
Disc Player.
System: Compact disc audio system
No of quantization bits 1 bit.
Usable disc: MP3/ CD-R/ CD-RW
Signal format: Sampling frequency 44.1 kHz
Frequency characteristics: 20-100 Hz 5 dB
10-20 kHz 5 dB
Signal to noise CD: 50 dB (1kHz)
Number of channels: 2 stereo
Line out
Output:
CD max 2000 mV
