Delta Electronics, Inc.

FEATURES

High efficiency: 90.5% @ 3.3V/35A

Industry standard quarter brick footprint

Size: 57.9x36.8x9.5mm(2.28”x1.45”x0.37”)

(w/o heatspreader)

57.9x36.8x12.7mm(2.28”x1.45”x0.50”)

(with heatspreader)

Fixed frequency operation

Input UVLO, Output OTP, OCP, OVP

Output voltage trim +10%, -20%

Monotonic startup into normal and pre-biased

loads

Outstanding dynamic response:

30mV for 25% load step

Very low output ripple

No minimum load required

Basic insulation

Frequency synchronization from external

signal

ISO 9001, TL 9000, ISO 14001, QS 9000,

OHSAS 18001 certified manufacturing facility

UL/cUL 60950 (US & Canada), TUV

(EN60950) and CE mark pending

DATABRIEF

DB_Q48SX_10272005

1

APPLICATIONS

Telecom/Datacom

Wireless Networks

Optical Network Equipment

Server and Data Storage

Industrial/Test Equipment

Medical Systems

OPTIONS

Surface mount version

Positive on/off logic

Delphi Series Q48SX, 35A Quarter Brick
DC/DC Power Modules: 48V in, 3.3V and 5.0V out

The Delphi Series Q48SX (XENA

TM

100), Quarter Brick, 48V input,

single output, isolated DC/DC converters are the latest offering from a
world leader in power systems technology and manufacturing ― Delta
Electronics, Inc. The Q48SX product family provides up to 125 watts of
power or 35A of output current in an industry standard quarter brick
footprint and pinout. The open frame construction is optimized for
convection cooling over a wide operational ambient temperature range.
With creative design technology and optimization of component
placement, these converters possess outstanding electrical and thermal
performance, as well as extremely high reliability under highly stressful
operating conditions. The output trim pin also serves as a
synchronization function that can greatly reduce output ripple/noise
when multiple Q48SX modules are used and linked together. This is a
big boost to those applications that are extremely noise sensitive. All
Q48SX models are fully protected from abnormal input/output voltage,
current, and temperature conditions. The Delphi Series converters meet
all safety requirements with basic insulation.
