RJ-45
For LAN display/network control and web server.
FLASH DRIVE
This connector supports USB flash drive display.
12V OUT
12V DC out
MIC
Microphone input jack.
AUDIO OUT
Connect to a speaker or other audio input equipment.
AUDIO-IN 1/AUDIO-IN 2
Connect an audio output from a computer to this jack.
AUDIO-IN 3 (L/R)
Connect an audio output from a video device to this jack.
VIDEO
Connect composite video output from video equipment to this jack.
VGA2-IN / YPbPr /
Connect image input signal (analog RGB or component) to this jack.
Support wireless dongle via internal power of VGA 2.
VGA1-IN / YPbPr
Connect image input signal (analog RGB or component) to this jack.
