DIXON -49
LUBRICATION
Lubricating the Cables
If possible, grease both ends of the cables and move the controls to end stop positions when lubricating. Refit the
rubber covers on the cables after lubrication. Cables with sheaths will bind if they are not lubricated regularly. If a
cable binds, it can disrupt operation.
If a cable binds, remove the cable and hang it vertically. Lubricate it with light engine oil until the oil begins to
escape from the bottom.
Tip: Fill a small plastic bag with oil and tape it so that it seals against the sheath and allow the cable to hang
vertically from the bag overnight. If you do not succeed in lubricating the cable, it must be replaced.
Following the Lubrication Schedule
Front Wheel Mount
Lubricate with a grease gun, one zerk for each wheel
mount, until the grease is forced out.
Use only good quality bearing grease.
Grease from well-known brand names (petrochemical
companies, etc.) usually maintains a good quality.
Front Wheel Bearings
Lubricate with a grease gun, one zerk for each set of
wheel bearings, until the grease is forced out.
Use only good quality bearing grease.
Deck Spindle
Lower the cutting deck completely.
If you use grease gun without rubber hose, the foot
plate must be removed.
Lubricate with a grease gun, one zerk, 2-3 strokes.
Use only good quality bearing grease.
8011-731
Lubricating the front wheels
8011-732
Deck spindle
IMPORTANT INFORMATION
Use minimal lubrication and remove
excess lubricant so that is does not come
into contact with belts or belt pulley drive
surfaces.
