CONTROLS
DIXON -23
8050-806
Cut height lift pedal
IMPORTANT INFORMATION
In order to obtain an even cutting height it is
important that the air pressure in all four tires
is the same 15 psi (1 bar).
IMPORTANT INFORMATION
Always use the high position to transport.
Mower Deck Cut Height Adjustment
Located on the right front of the frame, the lift lever
pedal controls the cutting height. The deck cutting
height is obtained by pressing the foot pedal forward to
lift the deck. To lower the deck, apply pressure to the
top side of the foot pedal and allow it to pivot into the
desired cutting height notch. Secure the desired cut
height with pin.
The cutting height range is from 1½" (38 mm) to 5½"
(140 mm) in ½" (13 mm) increments. The heights are
measured from the ground up to the blade tip with the
engine not running.
