TOYOTA 2010 Highlander - Manual (Page 463)

483
4-3. Do-it-yourself maintenance
4
Mainten
ance an
d ca
re
11 RR FOG 7.5 A No circuit
12 A/C NO.1 10 A Air conditioning system
13 FUEL OPN 7.5 A No circuit
14 S/ROOF 30 A Electric moon roof
15 TAIL 15 A
Parking lights, tail lights, license
plate lights, front fog lights, trailer
lights
16 PANEL 7.5 A
Glove box light, emergency flash-
ers, audio system, outside rear
view mirror defoggers, clock, power
door lock system, seat heaters,
rear seat entertainment system,
enhanced vehicle stability control
system, instrument panel light con-
trol dial, electronic controlled trans-
mission switch, automatic
transmission, downhill assist con-
trol system, steering switches
17 ECU IG NO.1 10 A
Multiplex communication system,
electric moon roof, electronically
controlled automatic transmission
system, power back door, seat
heaters, tire pressure warning sys-
tem, electronic power steering,
automatic transmission
18 ECU IG NO.2 7.5 A
Enhanced vehicle stability control
system
19 A/C NO.2 10 A Air conditioning system
20 WASH 20 A Windshield wipers and washer
21 S-HTR 20 A Seat heaters
Fuse Ampere Circuit
