DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
SMT Power Inductor
HAH1030 & HAH1040 Type
88
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
o
AT 25 C: 100KHz, 1.0V
Mechanical Dimension:
UNIT : mm / inch
A = 10.70 / 0.421 Max.
B = 10.00 0.254 / 0.394 0.010
D = 1.80 / 0.071 Ref
E = 3.00 / 0.118 Ref
Electrical Characteristics:
Features
RECOMMENDED PAD PATTERNS
A
B
C
E
D
2.40 / 0.094
11.20 / 0.441
5.42 / 0.213
1. Lo is the initial inductance and the tolerance of inductance is 20%.
2. Isat is the DC current which cause the inductance drop to Li.
O
3. Irms is the DC current which cause the surface temperature of the part increase less than 45
C.
O
O
4. Operating temperature : -40
C
to 125
C
( including self-temperature rise ).
L
(uH)
Li
(uH)
HEIGHT "C"
(mm/inch) MAX.
o
I
2
sat
(Adc)
(m ) MAX
DCR
rms
I
(Adc)
3
1
HAH1030-R47
0.47
0.376
2.1 10%
26
20
3.0 / 0.118
HAH1040-R15
0.15
0.12
0.8
30
30
4.0 / 0.157
HAH1040-0R2
0.20
0.15
0.8
45
45
4.0 / 0.157
HAH1040-R33
0.33
0.30
1.1
30
30
4.0 / 0.157
HAH1040-0R5
0.50
0.40
1.1
30
30
4.0 / 0.157
HAH1040-0R6
0.60
0.50
2.9
22
22
4.0 / 0.157
HAH1040-0R9
0.90
0.70
2.9
22
22
4.0 / 0.157
RoHS compliant.
Low profile, SMD type.
High current.
Magnetic shielded.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
