FORM NO. L-21204-C-0908 6
INSTALLATION
Figure 3
Mount the RSTC within a user-supplied enclosure, typically
the machine’s controls cabinet. The RSTC can be mounted
on 35 mm DIN rail or panel mounted (Refer to Figure 3).
CAUTION
Mount the RSTC in a shock and vibration free
area with an ambient temperature of less
than 140°F [60 C] and more than 32°F [0 C].
149.0
[5.87]
110.3
[4.34]
13.9
[0.55]
13.9
[0.55]
35.0
[1.38]
75.0
[2.95]
134.1
[5.28]
7.4
[0.29]
7.4
[0.29]
1.1
[0.04]
2X
60.2
[2.37]
R2.2
[0.09]
4X
