Wiring diagram, Pilot burner pilot gas line – Desa (V)T36ENA User Manual
Page 27
www.desatech.com
111251-01E
27
STEP DOWN
TRANSFORMER
PV
GND
PV/MV
TR
MV
TH
IG
N
EV2
INCOMING MAIN
GAS SUPPLY
EV1
GAS LINE TO
BURNER
24V AC
120V AC
INCOMING
120V AC
(FUSE BOX
OR BREAKER)
OFF
ON
WALL SWITCH
(NOT SUPPLIED)
GREEN
BLA
CK
WHITE
120v, 60Hz, 0.7A
ELECTRICAL RATING:
BLACK
WHITE
GREEN
OPTIONAL
REMOTE
CONTROL
Pilot Burner
Pilot Gas
Line
WIRING DIAGRAM
