WaterFurnace Envision Hydronic (NDW) - Manual (Page 34)

34
NDW INSTALLATION MANUAL
Service Parts List
Part Description
100 120
208-
230/60/1
208-
230/60/3
460/60/3 575/60/3
208-
230/60/3
208-
230/60/3
460/60/3 575/60/3
R
efriger
ation
C
omponents
Compressor 34P580-01 34P580-03 34P580-04 34P580-05 34P616-01 34P616-03 34P616-04 34P616-05
Compressor Sound Jacket 92P504A05 92P519-02
Thermal Expansion Valve 33P608-18 33P605-12
Filter Dryer 36P500B02 36P500B02
Reversing Valve with Coil 33P526-04 33P526-04
Brazed Plate Heat Exchanger 62P565-01 62P565-01
Heat Exchanger Support Bracket 47F588-01 47F588-01
Saf
eties /
Sensors
High Pressure Switch 35P506B02 35P506B02
Low Pressure Switch 35P506B01 35P506B01
Water Temperature Sensor 12P529-04 12P529-04
Low Water Coil Temp Sensor 12S529-01 12S529-01
Electrical
Compressor Contactor 13P004A03 13P537B03 13P004A03 13P537B03
Transformer 15P501B01 15P505B01 15P506B01 15P501B01 15P505B01 15P506B01
Power In Terminal Block 12P524A01 12P524A01
Connection Block - Small 12P503-06 12P503-06
Connection Block - Low Voltage 12P520-01 12P520-01
Grounding Lug 12P004A 12P004A
C
ontr
ol
FX10 Main Board - no communications 17X51606-09 17X51606-09
FX10 Main Board & N2 Open Com Card 17X51606-10 17X51606-10
FX10 Main Board & Lonworks Com Card 17X51606-12 17X51606-12
FX10 Main Board & BACnet Com Card 17X51606-11 17X51606-11
FX10 Expansion Board 17P516-07 17P516-07
Display 19P563-01 19P563-01
FX10 Display Interface Board 17P516-11 17P516-11
Cabinet
Side Access Panel 40C661-01 40C661-01
Front/Back Access Panel 40C662-01 40C662-01
Top Panel (back mount) 42C547-01 42C547-01
Top Panel - Large (top mount) 42C547-02 42C547-02
Top Panel - Small (top mount) 42C547-03 42C547-03
5/6/09
Part Description
150 180
208-
230/60/3
208-
230/60/3
460/60/3 575/60/3
208-
230/60/3
208-
230/60/3
460/60/3 575/60/3
R
efriger
ation
C
omponents
Compressor 34P614-01 34P614-03 34P614-04 34P614-05 34P609-01 34P605-03 34P605-04 34P605-05
Compressor Sound Jacket 92P519-02 92P519-02
Thermal Expansion Valve 33P605-13 33P605-14
Filter Dryer 36P500B02 36P500B02
Reversing Valve with Coil 33P526-04 33P526-04
Brazed Plate Heat Exchanger 62P565-01 62P565-01
Heat Exchanger Support Bracket 47F588-01 47F588-01
Saf
eties /
Sensors
High Pressure Switch 35P506B02 35P506B02
Low Pressure Switch 35P506B01 35P506B01
Water Temperature Sensor 12P529-04 12P529-04
Low Water Coil Temp Sensor 12S529-01 12S529-01
Electrical
Compressor Contactor 13P004A03 13P537B03 13P004A03 13P537B03
Transformer 15P501B01 15P505B01 15P506B01 15P501B01 15P505B01 15P506B01
Power In Terminal Block 12P524A01 12P524A01
Connection Block - Small 12P503-06 12P503-06
Connection Block - Low Voltage 12P520-01 12P520-01
Grounding Lug 12P004A 12P004A
C
ontr
ol
FX10 Main Board - no communications 17X51606-09 17X51606-09
FX10 Main Board & N2 Open Com Card 17X51606-10 17X51606-10
FX10 Main Board & Lonworks Com Card 17X51606-12 17X51606-12
FX10 Main Board & BACnet Com Card 17X51606-11 17X51606-11
FX10 Expansion Board 17P516-07 17P516-07
Display 19P563-01 19P563-01
FX10 Display Interface Board 17P516-11 17P516-11
Cabinet
Side Access Panel 40C661-01 40C661-01
Front/Back Access Panel 40C662-01 40C662-01
Top Panel (back mount) 42C547-01 42C547-01
Top Panel - Large (top mount) 42C547-02 42C547-02
Top Panel - Small (top mount) 42C547-03 42C547-03
5/6/09
