Page 5
Part No. 8N301-040
Vortech Maxflow
Power Cooler
1996 - 1998 Ford 4.6 Mustang Cobra (4 Valve)
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report
any shortages or damaged parts immediately.
PARTS LIST
PART NUMBER
DESCRIPTION
QUANTITY
8N101-040
Air/Water Aftercooler 4V
1
7S275-300
2-3/4” x 3” Sleeve
1
8N012-060
Cooler Discharge Tube 4V 4.6
1
7S375-200
3-3/4” x 2” Sleeve
1
7R002-060
No. 60 Goldseal Hose Clamps
2
7P500-078
1/2 NPT x 3/4 Hose Fitting
2
Air/Water Aftercooler Assembly (8N201-040)
PART NUMBER
DESCRIPTION
QUANTITY
8N105-010
Water Tank w/ Fittings
1
7U038-000
3/4” Heater Hose (228”)
19’
7R007-001
Plastic Double Grip Clamps
7
7R003-016
15/16” Adel Clamps
3
7E010-075
#12 x 3/4 HXHD
3
7J010-001
#10 Flat Washer
3
7U100-044
Nylon Tie Wraps 4”
16
7U100-066
Nylon Tie Wraps 11”
6
Water Tank Assembly (8N105-030)
PART NUMBER
DESCRIPTION
QUANTITY
8N006-010
Water Cooler
1
7P500-026
90
°
Brass Fittings
2
8N010-050
Mounting Tabs
2
7E010-075
#12 x 3/4 HXHD Sheet Metal
4
7J010-001
#10 Flat Washer
4
7A250-075
1/4-20 x 3/4 SHCS
5
7F250-021
1/4-20 Nylock
5
7J250-001
1/4” Flat Washer
10
Water Cooler Assembly (8N106-030)
PART NUMBER
DESCRIPTION
QUANTITY
8F001-403
Water Pump
1
8N010-060
Bracket, Bosch Water Pump
1
5W001-011
14-16 GA Eyelet
1
5W001-012
18-22 GA Butt Connector
1
5W018-010
18 GA Strd Wire Red (99”)
8.25’
5W001-019
12 GA Butt Connector
1
5W001-014
Fuse Holder
1
5W001-015
Fuse Blade Style
1
5W001-002
Fuse Tap
1
5W001-040
12-10GA Female Slide
1
5W001-050
Connector, Fuel Injector
1
7E010-075
#12 x 3/4” Sheet Metal Screw
2
7J010-001
#10 Flat Washer
2
7U133-060
3/4” x 90
°
Hose Elbow
1
PART NUMBER
DESCRIPTION
QUANTITY
2A100-030
Retainer, Volute 1/2 size
2
7U133-024
5/8” Molded Elbow Hose
1
7U133-060
3/4” x 90
°
Hose Elbow
1
7P625-016
5/8” Union
1
7P375-075
3/4” Hose Barb
1
2A036-325
Supercharger Pulley, 3.25” 6 Groove 1
Support Components (8N104-030)
Water Pump Assembly (8N107-020)
