Specifications
4 Technical data
Designation Characteristics
GTR/LINE Input
Jack 6.35mm (1/4") balanced (TRS, Tip/Ring/Sleeve). We recommend the use of a TS
jack cable if the output of the product/instrument you plug into the TORPEDO C.A.B. is
unbalanced.
IN LEVEL switch sets level and impedance of the input.
GTR:
• Max input level 4.7dBu
• Impedance 100KOhms
LINE:
• Max input level 10.3dBu
• Impedance 10KOhms
AMP/LINE Output
Jack 6.35mm (1/4") balanced (TRS)
Impedance: 470 Ohms
OUT LEVEL switch sets the output level.
AMP: maximum output levels
• No load, balanced: 10.7dBu
• 10KOhms load, balanced: 10.5dBu
• No load, unbalanced: 4.7dBu
• 10KOhms load, unbalanced: 4.2dBu
Line: maximum output levels
• No load, balanced: 16.5dBu
• 10KOhms load, balanced: 16.3dBu
• No load, unbalanced: 10.5dBu
• 10KOhms load, unbalanced: 10dBu
Noise: less than -94 dBu from 20 Hz to 20 KHz
Headphones Output MONO out, Jack 6.35mm (1/4") balanced (TRS)
