TK Audio S-Blender - Manual (Page 3)

Main level
The main level is placed right before the main output.
Monitor section
The monitor signal is fed directly from the output connectors through its own dedicated level
control. A mono switch is also provided for checking mono compatibility. The mono switch
does not affect the main signal.
Chassi ground
A chassi to audio ground jumper is located on the main circuit board right behind the Ch2
mute switch.
115V / 230V main power
A voltage selector is placed inside the unit to the right of the blue main transformer.
The main fuse is located in the AC-inlet. Use 100mA for 230V and 200mA for 115V.
Inputs and outputs
All male connectors are outputs and all female connectors are inputs. All in- and outputs are
electronically balanced.
Input impedance 24 Kohm. Output impedance 50 ohm.
EU - Declaration of conformity
Product
TK Audio S-Blender / Mini Mastering Console
115v - 200mA, 230v - 100mA
Manufactor
Thomas Kristiansson
Musikverkstan / TK Audio
Falkenbergsgatan 10
30233 Halmstad
Sweden
Halmstad, April 2013
Declaration of conformity
I declare under my sole responsibilty that this product, to which this declaration relates, is
in confomity with the following standards:
EN55013, EN55020:2002, EN61000-3-2, EN61000-4-2 and EN60065
Following the provision of 73/23/EEC, 89/336/EEC and 93/68/EEC.
