10
g. Continuity Buzzer
Test Voltage Threshold Over Load Protection
3V 1000 digits 600 V DC or Peak AC
h. Capacitance
Range Resolution Accuracy Over Load Protection
10µF 0.01µF ±2% of reading, 600V DC or
100µF 0.1µF ±5 digits Peak AC
1000µF 1µF
10,000µF 1µF ±3% of reading, ±7 digits
i. Frequency
Range Resolution Accuracy Over Load Protection
200.00Hz 0.01Hz ±0.05% of reading, 600V DC or
2.0000kHz 0.0001kHz ±2 digits Peak AC
20.000kHz 0.001kHz
200.00kHz 0.01kHz
l. General Specifications
Max. Volt. between 1000V
any Input and Ground
Fuse Protection
mA: 0.5Amp/600VAC; A: 10Amp/600VAC
Display Type, Digital: 4,000 Count, 4 times per second update
Analog: 2x41 segments, 20 times per sec. update
Operating Temp. -0° to 40°C (32° to 113°F)
Storage Temp. -20° to 60°C (-4° to 140°F)
Relative Humidity 0% to 80%: (0° - 35°C/32° - 95°F)
0% to 70%: (35° - 55°C/95° - 131°F)
Temp. Coefficient 0.1 x (Specified Accuracy) per °C for
temperature <18°C to >28°C
Power Supply 9 Volt Battery
Battery Life 100 hrs. Alkaline
Size (H x L x W) 33mm x 86mm x 187mm (1.3” x 3.4” x
7.4”)
Weight
380g (14.4oz)
c. DCA
Range Resolution Accuracy Overload
Protection
400µA 0.1µA ±0.5% of reading, Fuse**(fast blow)
4000µA 1µA ±5 digits F600V, .5A, 31CM
40mA 0.01mA
400mA 0.1mA
4A 0.001A ±0.75% of reading, Fuse**(fast blow)
10A 0.01A ±5 digits F600V, 10A, 31CM
d. ACA
Range Resolution Accuracy Overload
Protection
400µA 0.1µA ±0.75% of reading, Fuse**(fast blow)
4000µA 1µa ±5 digits F600V, .5A, 31CM
40mA 0.01mA
400mA 0.1mA
4A 0.001A ±1% of reading, Fuse**(fast blow)
10A 0.01A ±5 digits F600V, 10A, 31CM
e. OHM (Resistance, )
Range Resolution Accuracy Overload
Protection
400
Ω
0.1
Ω
±0. 5% of reading, 600V DC or
4k
Ω
0.001k
Ω ±5 digits
AC Peak
40k Ω 0.01k Ω
400k Ω 0.1k Ω
4M
Ω
0.001M
Ω ±1% of reading,
40M
Ω
0.01M
Ω ±10 digits
f. Diode Test
Test Voltage Max Test Current Over Load Protection
3V Approx. 2.5mA 600 V DC or Peak AC
**Warning: Use only correct size, voltage and current rated fuses.
Test Leads: Use only correct type and overvoltage category rating.
3. Specifications (cont.) 3. Specifications (cont.)
11
