Test Products International 163 - Manual (Page 8)

8 9
Fuse* (fast blow)
3260mA 0.001mA
±2 digits F600V, .5A, 31CM
32.6mA 0.01mA ±1.5% of reading,
326mA 0.1mA ±2 digits
10A 0.01A ±2% of reading, Fuse* (fast blow)
±2 digits F600V, 10A, 31CM
d. ACA
Range Resolution Accuracy Overload Protection
326µA 0.1µA ±2% of reading, Fuse* (fast blow)
3260µA 1µA ±5 digits F600V, .5A, 31CM
32.60mA 0.01mA
326mA
0.1mA
10A 0.01A ±2.5% of reading, Fuse* (fast blow)
±5 digits F600V, 10A, 31CM
e. OHM (Resistance, )
Range Resolution Accuracy Overload Protection
326 Ω 0.1 Ω ±1% of reading, 450V DC or
3.26k
Ω 0.001kΩ
±2 digits AC Peak
32.6k
Ω 0.01kΩ
326k Ω 0.1k Ω
3.26M Ω 0.001MΩ
±2% of reading, ±2 digits
32.6M
Ω 0.01MΩ
±3.5% of reading, ±4 digits
f. Diode Test
Test Voltage Max Test Current Over Load Protection
3V Approx. 0.5mA 600 V DC or Peak AC
g. Continuity Buzzer
Test Voltage Threshold Over Load Protection
1.2V < 20
Ω
600 V DC or Peak AC
h. General Specifications
Max. Volt. between 1000V
any Input and Ground
3. Specifications
IEC 1010 Over Voltage:
CAT II - 1000V
CAT III - 600V
Pollution Degree 2
a. DCV
Range Resolution Accuracy Impedance
326mV 0.1mV ±0.5% of reading, 10M
Ω
3.26V 0.001V ±2 digits
32.60V 0.01V ±1.0% of reading,
326V 0.1V ±2 digits
1000V 1V
b. ACV
Range Resolution Accuracy Impedance
3.26V 0.001V ±1.2% of reading, 10M
Ω
32.6V 0.01V ±4 digits
326V 0.1V
750V 1V
c. DCA
Range Resolution Accuracy Overload Protection
326µA 0.1µA ±1% of reading, Fuse* (fast blow)
3260mA 0.001mA ±2 digits F600V, .5A, 31CM
32.6mA 0.01mA ±1.5% of reading,
326mA 0.1mA ±2 digits
10A 0.01A ±2% of reading, Fuse* (fast blow)
±2 digits F600V, 10A, 31CM
*Warning: Use only correct size, voltage and current rated fuses.
Test Leads: Use only correct type and overvoltage category rating.
*Warning: Use only correct size, voltage and current rated fuses.
Test Leads: Use only correct type and overvoltage category rating.
UL 3111-1
