Test Products International 163 User Manual
Page 20
20
21
4.
Set the rotary switch to the
function.
5.
Press the Range/Diode/Continuity button
so that
shows on the LCD.
6.
Connect the black test lead to the banded
end of the diode and the red test lead to
the non-banded end of the diode.
7.
Reading on the display should be between
0.3 and 0.8 volts.
8.
Reverse test lead connections in 6 above.
9.
Reading on the display should be OFL
(Overload).
NOTE: If diode reads 0 in both directions, diode is short-
ed. If diode reads OFL in both directions, diode is open.
g.
CONTINUITY BUZZER
WARNING!
Do not attempt to make continuity measurements
with circuit energized.
Instrument set-up:
FUNCTION
BLACK RED
TEST LEAD
TEST LEAD
COM
V
Ω
Measurement Procedure:
1.
Disconnect power to the circuit to be measured.
2.
Plug the black test lead into the COM input jack.
Instrument set-up:
FUNCTION BLACK RED
MINIMUM
MAXIMUM
TEST LEAD
TEST LEAD
READING
READING
Ω
COM
V
Ω
0.1
Ω
32.6M
Measurement Procedure:
1.
Disconnect power to the circuit to be measured.
2.
Plug the black test lead into the COM input jack.
3.
Plug the red test lead into the V
Ω
input jack.
4.
Set the rotary switch on the 163 to the
Ω function.
5.
Connect the test leads to the circuit to be measured.
6.
Read the resistance value on the 163.
f.
MEASURING DIODES
CAUTION!
Do not attempt to make diode measurements with
circuit energized. The only way to accurately test
a diode is to remove it completely from the circuit
before attempting to measure it.
Instrument set-up:
FUNCTION
BLACK RED
MINIMUM
MAXIMUM
TEST LEAD
TEST LEAD
READING
READING
COM
V
Ω
0.001V
2.000V
Measurement Procedure:
1.
Disconnect power to the circuit to be measured.
2.
Plug the black test lead into the COM input jack.
3.
Plug the red test lead into the V
Ω
input jack.
