163 SPECIFICATIONS
±0.5% Basic DCV Accuracy (also see pages 8-9)
Function Range Resolution
DCV 326mV 0.1mV
3.26V 0.001V
32.6V 0.01V
326V 0.1V
1000V 1V
ACV 3.26V 0.001V
32.6V 0.01V
326V 0.1V
750V 1V
DCA 326µA 0.1µA
3260mA 0.001mA
32.6mA 0.01mA
326mA 0.1mA
10A 0.01A
ACA 326µA 0.1µA
3260µA 1µA
32.6mA 0.01mA
326mA 0.1mA
10A 0.01A
OHM 326 Ω 0.1 Ω
3.26k Ω 0.001k Ω
32.6k Ω 0.01k Ω
326k Ω 0.1k Ω
3.26M Ω 0.001M Ω
32.6M Ω 0.01M Ω
Test Voltage Max. Test Current
Diode 3V Approx. 0.5mA
Test Voltage Threshold
Continuity 1.2V <20 Ω
