Removing the cover plate – StorCase Technology 14-Bay 3U Fibre User Manual
Page 14
InfoStation 14-Bay FC Installation Guide - Rev. B00
StorCase Technology, Inc.
Installation
9
Figure 7: Removing the Cover Plate
Removing the Cover Plate
NOTES:
A #2 Phillips screwdriver will be required for this procedure.
Blank plate (provided) must be installed if module slot is left empty. Installation
of the blank plate is necessary for proper cooling inside chassis.
1.
Remove the Phillips F. H. screw securing the cover plate to the InfoStation chassis
(Figure 7).
4.
Remove the cover plate (Figure 7).
5.
To reinstall cover plate, simply reverse the above mentioned steps.
Cover
Plate
Screw
14FC_10
