2 Introduction
StorCase Technology, Inc. DS322 User's Guide - Rev. A02
Figure 1: Data Silo DS322
General Description
WARNING: The DS322 contains NO USER SERVICEABLE PARTS inside the unit. Refer
ALL servicing to qualified service personnel!
The StorCase Technology Data Silo ® DS322 2-bay expansion chassis with FireWire
(IEEE-1394) interface and Data Express ® DE110 removable drive enclosures provide durable
and reliable mounting for two (2) 3.5" form factor, low-profile (1" high) Ultra ATA/100 drives.
It is downward compatible with earlier technology IDE drives.
The DS322 is available in a 2U rack mount, dual bay configuration (Figure 1). Each chassis
is constructed of rugged steel and is equipped with one (1) 65W auto-ranging power supply,
chassis status LED, two (2) adjustable-speed blowers, and all necessary internal wiring and
drive mounting hardware.
The DS322 comes standard with two (2) dual port FireWire (IEEE-1394) interfaces, which
allow for single or dual host configurability.
