10 Installation
StorCase Technology, Inc. DE75i-SWC160 User's Guide - Rev. B01
IMPORTANT NOTE: In order to use remote ID selection from the computer or
expansion chassis, the Unit ID number on the Data Express
receiving frame must be set to "0" with the provided
alignment tool. Refer to the section "Selecting the Unit ID
Number" later in this manual for the Unit ID selection
procedure.
1 ID0 SCSI ID
2 GND Ground
3 ID1 SCSI ID
4 GND Ground
5 ID2 SCSI iD
6 GND Ground
7 ID3 SCSI ID
8 GND Ground
9 SYNC Drive Synchronization Signal
10 GND Ground
11 RLEDA Remote LED Anode
12 RLEDC Remote LED Cathode
13 DFAULT Force Drive Fault Signal to Display
14 GND Ground
15 NC No Connect
16 GND Ground
17 RMTST Remote Start
18 GND Ground
19 DLYST Delay Start
20 GND Ground
21 LKA For Factory Use Only
22 LKB For factory Use Only
Table 1: Option Pin Connector Signal Descriptions
PIN Signal Function
