2 Introduction
StorCase Technology, Inc. DE75i-S User's Guide - Rev. A01
Package Contents
The DE75i-S product shipment should include the following items. If any item is missing or
damaged, contact your StorCase dealer for a replacement.
Figure 1: Package Contents
6. #6-32 Phillips F.H. Mounting Screws
7. Alignment Tool
8. SCSI ID Select Cable (0.1"/1.25mm)
9. SCSI ID Select Cable (0.1"/2mm)
10. Drive Cover
11. Insert Sheet
1. Drive Carrier
2. 5.25" Adapter Bracket
(shown installed)
3. Receiving Frame
4. #6-32 Phillips Machine Hd.
Screws
5. Drive Lock Keys
4
7
10
5
1
3
8
9
6
2
11
Data E
xpres
s
Drive C arrier
Disk D rive (Not In cluded ) Power Cable I/O Ca ble
Drive M ountin g Hardw are (4 ea) Phillip s # 6-3 2 x 3/16 F lat HD
ID Sele ct Cab le
0151
Cable Cover (Provid ed)
Cable Cove r Screw s (2 plc s) # 6-32 x 3/16 Flat H D
0667a
