-4-
The in-line flasher unit has twenty-five different
Flash Patterns to select from.
(see chart to right)
These patterns include:
• 12 different patterns in each of two
different Phases.
• A Steady Burn Pattern
Head 2
P
h
a
s
e
2
C
y
c
le
2
P
h
a
s
e
2
T
IM
E
P
h
a
s
e
1
Head 1
C
y
c
le
1 P
h
a
s
e
1
Head 1
(ON) (OFF)
Head 2
2 Complete flash cycles 2 Complete flash cycles
Programming Procedure:
1. If you are NOT synchronizing your flasher
with another flasher or approved light, tape
the WHITE wire off so that it does not come
into contact with anything.
2. The GREEN wire is used to program the
desired flash pattern. After the BLACK
and RED wires are connected (see
previous page), you may set the flash
pattern. The flasher is programmed at
the factory for Pattern 6 (Pattern Type F
– Quadflash Phase 1). To change the
pattern, proceed below:
• Touch and hold the green wire to
ground until the light blinks once
(approximately 3 seconds), then
release it. This will reset the light to
Pattern 1 (Pattern Type K – Flicker
Phase 1).
• Touch the green wire to ground
for approximately 1 second and
release it to cycle through
Patterns 1-24 shown to the
right. After Pattern 24, the light
will cycle back to Pattern 1.
• To access the Steady Burn
pattern, touch the green wire to
ground for approximately 18
seconds and release it after the
light blinks 5 quick times (once,
then twice, then three times,
then four times, then five times).
Programming Shortcuts
Touch the Green Wire to Ground For: Unit Blinks Jumps To
3 seconds 1 time Pattern 1
6 seconds 2 times Pattern 6
9 seconds 3 times Pattern 13
12 seconds 4 times Pattern 18
18 seconds 5 times Steady Mode
Pattern Programming
F
la
s
h
P
a
tt
e
rn
#
P
a
tt
e
rn
T
y
p
e
P
h
a
s
e Pattern
Description
C
P
S
S
h
o
rt
c
u
t (
H
o
ld
to
G
ro
u
n
d
)
1 K
1
Flicker 1.0 3 sec
2 L Fast Doubleflash 3.3
3 M Tripleflash 2.5
4 N PSU-flicker 0.7
5 O PSU Random 0.6
6 F Quadflash 1.0 6 sec
7 G Quadflash w/Post-Pop 1.0
8 H Singleflash 1.0
9 I Doubleflash 1.0
10 J Delta-Omega 0.3
11 C Post Pop 1.4
12 E Random 0.4
13 K
2
Flicker 1.0 9 sec
14 L Fast Doubleflash 3.3
15 M Tripleflash 2.5
16 N PSU-flicker 0.7
17 O PSU Random 0.6
18 F Quadflash 1.0 12 sec
19 G Quadflash w/Post-Pop 1.0
20 H Singleflash 1.0
21 I Doubleflash 1.0
22 J Delta-Omega 0.3
23 C Post Pop 1.4
24 E Random 0.4
25 N/A Steady N/A 18 sec
