Spectrum Controls 1746sc-OAP8I - Manual (Page 27)

Installation Instructions
Isolated-Circuit
Discrete Input and Output Modules
Ask your distributor about these other Allen-Bradley compatible products
from Spectrum Controls:
Catalog No. Description
1746sc-INI4vi Isolated-Channel Analog Inputs (4)
Each Current or Voltage Selectable
1746sc-INI4i Isolated-Channel Analog Inputs (4)
Current only
1746sc-INO4vi Isolated-Channel Analog Outputs (4)
Each Current or Voltage Selectable
1746sc-INO4i Isolated-Channel Analog Outputs (4)
Current only
1746sc-IA8I Isolated-Circuit 100/120 V ac/dc Inputs (8)
1746sc-IB8I Isolated-Circuit 24 Vdc Inputs (8)
1746sc-IC8I Isolated-Circuit 48 Vdc Inputs (8)
1746sc-IM8I Isolated-Circuit 200/240 V ac/dc Inputs (8)
1746sc-OAP8I Isolated-Circuit 120/240 Vac Outputs (8)
1771sc-IMI16 Isolated-Circuit 200/240 V ac/dc Inputs (16)
1771sc-OMI16 Isolated-Circuit 120/240 Vac Triac Outputs (16)
Each Fuse Protected
