Installation Instructions

Isolated-Circuit
Discrete Input and Output Modules

19

1746sc-IC8I

Isolated-Circuit 48 Vdc Inputs (8)

VDC
0+

VDC
1+

VDC
2+

VDC
3+

E-GND

VDC
4+

VDC
5+

VDC
6+

VDC
7+

IN 0–

IN 1–

IN 2–

IN 3–

E-GND

IN 4–

IN 5–

IN 6–

IN 7–

VS0 DC COM 0

VS0 +VDC

Alternative
input device
location

48 Vdc*

VS1 DC COM 1

VS2 DC COM 2

VS3 DC COM 3

VS4 DC COM 4

VS5 DC COM 5

VS6 DC COM 6

VS7 DC COM 7

Rack mounting bolt

VS1 +VDC

VS2 +VDC

VS3 +VDC

VS4 +VDC

VS5 +VDC

VS6 +VDC

VS7 +VDC

Note — The input circuits are electrically isolated from each other (the commons are NOT connected
internally). Therefore, up to eight different voltage sources (VS0–VS7) may be used.

* Inputs are bipolar and may be connected without regard to polarity.

Module ID Code = 324
