Micro800™ 4 Ch Universal Thermistor Input Module 7
Publication 0100198-01 Rev. A
Configuration Tags
This table shows the tags in the sample ladder program for configuration.
Details are described in the sub-sections that follow.
Register
Data
Type
Comments
S1_CFG_Trigger INT
Transition from 0 to non-
zero to trigger new config.
S1_CFG_CH_n_Params[0] INT Configuration Bits
S1_CFG_CH_n_Params[1] INT
Maximum Range (default
19016)
Degrees C x100 or
ohms div 10
Default: 19016
S1_CFG_CH_n_Params[2] INT
Minimum Range
Degrees C x100 or
ohms div 10
Default: 0
S1_CFG_CH_n_String[0] STRING
-COEFF-A for Steinhart-
Hart Equation
-BETA for BETA Equation
S1_CFG_CH_n_String[1] STRING
-COEFF-B for Steinhart-
Hart Equation
-Resistance @25C for
BETA Equation
S1_CFG_CH_n_String[2] STRING
-COEFF-C for Steinhart-
Hart Equation
Ignored for BETA Equation
