Speck Electronics Xtramix - Manual (Page 56)

Connector
Matrix for
XTRAMIXc
xi
Notes:
All Input and output
connectors on the
Input / Output
Connection
Connector
Type
Recommend
Connector
Notes
Synth/Line Inputs 1-20 ¼” T.R.S. Switchcraft #297 Balanced
Effects Returns 1-8 ¼” T.R.S. Switchcraft #297 Balanced
Line Returns 1-8 ¼” T.RS. Switchcraft #297 Balanced
Aux Return L & R ¼” T.S Switchcraft #280 Unbalanced
Cue Return L & R ¼” T.S. Switchcraft #280 Unbalanced
Subgroup Outputs 1-8 ¼” T.R.S. Switchcraft #297 Balanced
Subgroup inserts 1-8 ¼” T.R.S. Switchcraft #297 Tip=Return, Ring=Send
Program Outputs L & R ¼” T.R.S. Switchcraft #297 Balanced
Program Inserts L & R ¼” T.R.S. Switchcraft #297 Tip=Return, Ring=Send
Monitor Outputs L & R ¼” T.R.S. Switchcraft #297 Balanced
Effects Sends 1-8 ¼” T.R.S. Switchcraft #297 Balanced
Effects Sum 1-8 ¼” T.R.S. Switchcraft #297 Unbalanced
Tuner Output ¼” T.R.S. Switchcraft #297 Balanced
Headphone Output ¼” T.R.S. Tip=Left, Ring=Right
Connector Matrix for XTRAMIXcxi - Version 5
Important Notes:
All Input and output connectors on the Xtramix use the highest quality Swichcraft SN37A series
jacks. Switchcraft brand mating plugs are therefore recommended because of their 100%
compatibility, reliability and durability.
Neutrik brand plugs may also be used as an alternate.
Cables with molded plugs or any “off-brand” plugs that do not meet the exact mechanical
specifications of Switchcraft are not recommended for use with the Xtramix.
The results from using “off-brand” plugs may vary from intermittent signals to a complete loss of
signal connection or oscillation.
51 Appendix B
