Speck Electronics Xtramix - Manual (Page 10)

The Xtramix is supplied with a set of rack mount adapters. If the
intention is to mount the Xtramix in a standard 19" equipment rack,
these adapters must be mounted to the left and right sides of the mixer.
CAUTION!
IMPORTANT!
ALWAYS CHECK THE PROPER OPERATING VOLTAGE
BEFORE OPERATING THE XTRAMIX.
USE ONLY THE POWER SUPPLY THAT IS
SPECIFIED FOR YOUR PRODUCT.
Rack mount adapters
Specifications
5
Line Input Impedance
Effects Return Input Impedance
Cue Return Input Impedance
Aux Return Input Impedance
Subgroup Insert Return Impedance
Effects Sum In Impedance
Effect Send Output Impedance
Program Feed Output Impedance
Monitor Feed Output Impedance
Tuner Feed Output Impedance
Subgroup Feed Output Impedance
Subgroup Insert Send Impedance
Line Input Level (High Level)
Line Input Level (Low Level)
Effects Return Input Level
Subgroup Insert Return Level
Cue Return Input Level
Aux Return Input Level
Normal
0dBu
-20dBu
+4dBu
+4dBu
+4dBu
+4dBu
Maximum
+28dBu
+10dBu
+21dBu
+21dBu
+21dBu
+21dBu
15k Ohms
15k Ohms
15k Ohms
15k Ohms
5k Ohms
10k Ohms
All line outputs are designed to drive a
600 ohm load and may be operated
into any load 600 ohms or greater.
Chapter 1 Introduction Section
