PARTS LIST FOR 2S2300SR SKIN CLAMP RUNNER
SERIAL “C”
Fig. Part
No. No. Description
Fig. Part
No. No. Description
*Order Quantity As Required
FURNISH CATALOG, SERIAL, AND MODEL NUMBER WHEN
ORDERING PARTS
1. 65009 Screw—M4 x .7 (10)*
2. 21491 Ring—Retainer
3. 68268 Ass’y—Housing
4. 44383 Shaft—Cluster Gear
5. 30235 Pin—Roll 3/32" x 3/8"
6. 35098 Washer (2)*
7. 10041 Bearing—Needle (2)*
8. 68231 Ass’y—Gear & Bearing
9. 13202 Spacer—Sleeve
10. 10220 Bearing—Ball
11. 68234 Ass’y—End Plate & Bearing
12. 64108 Cylinder (Reversing)
13. 63192 Vane—Rotor (Set of 5)
14. 68230 Rotor
15. 10552 Plate—Upper End
16. 10230 Bearing—Ball
17. 65008 Gasket
18. 65027 Back Cap (Reversing)
19. 14323 Ring—“O” 1/16" x 1/4" x 1/8"
20. 65016 Ass’y—Speed Control
21. 14371 Ring—“O” 1/16" x 1-5/16" x 1-3/16"
22. 65030 Deflector—Exhaust
23. 54837 Intake Adaptor—1/4" NPT
54837Y Intake Adaptor—1/4" BSPT
53942 IntakeAdaptor—1/4" NPT Remote Exhaust
24. 30463 Screen
25. 65040 Pad—Silencer
26. 14312 Ring—“O” (4)* 1/16" x 9/16" x 7/16"
27. 21541 Ring—Retainer
28. 09954 Screw—Drive #0 x 3/16 (2)*
29. 65010 Plate—Name
30. 21401 Spring
31. 14325 Valve
34. 65013 Ass’y—Valve
35. 30499 Pin—Roll 3/32" x 11/16"
36. 65002 Trigger
37. 10104 Bearing—Ball
38. 65018 Gear—Face
39. 65001 Spacer—Chuck Spindle
40. 21766 Ring—Retainer
43. 65005 Rod—Valve
46. 65023 Seat—Valve
47. 65025 Ring—Retainer
48. 65007 Valve—Reversing
49. 65026 Ring—“O” (Teflon)
61. 65287 Spindle—Tool
62. 44353 Adaptor—Clutch Case
63. 1365 Exhaust Tube (Includes Fig. 21 & 64)
64. 43210 Ass’y—Spring Clip (Remote Exhaust)
65. 1359 Air Hose (Remote Exhaust)
70. 65039 Liner—Back Cap (2)*
72. 65038 Bail
73. 21392 Spring
74. 65271 Plunger—Detent
75. 35315 Spacer
76. 21447 Bail
Not Shown
3303 Kit—Remote Exhaust (Includes Fig. 23, 63, 65)
