Sioux Tools SZEA8000 User Manual
Page 31
31
*Order Quantity As Required
**Option Item Sold Separately
FURNISH CATALOG, SERIAL, AND MODEL NUMBER WHEN ORDERING PARTS
Fig.
Part
No.
No.
Description
PARTS LIST FOR SZEA8000
COMPRESSION RIVETERS – “C” YOKE STYLE
Fig.
Part
No.
No.
Description
1.
SZC15HD
C-Yoke 1-1/2", 3/16"Ø Set Hole (SZEA8015)
SZC15HD2
C-Yoke 1-1/2", 1/4"Ø Set Hole (SZEA80152)
SZC20HD
C-Yoke 2", 3/16"Ø Set Hole (SZEA8020)
SZC20HD2
C-Yoke 2", 1/4"Ø Set Hole (SZEA80202)
SZC25HD
C-Yoke 2-1/2", 3/16"Ø Set Hole (SZEA8025)
SZC25HD2
C-Yoke 2-1/2", 1/4"Ø Set Hole (SZEA80252)
SZC30HD
C-Yoke 3-1/2", 3/16"Ø Set Hole (SZEA8030)
SZC30HD2
C-Yoke 3-1/2", 1/4"Ø Set Hole (SZEA80302)
2.
SZ11801
Spring
3. SZ67-L50D6H3
Set Holder
(3-1/8" L X 7/16"Ø X 3/16" Set Hole Size)
4.
SZ65
Yoke Bolt (3)*
5.
SZ66
Yoke Bolt Nut (3)*
6.
SZ01902
Yoke Plate
7.
SZ13903
Lever
8.
SZ30
Pivot Bearing
9.
SZ72
Throttle Valve Lever
10.
SZ27904
Cover Guard
11.
SZ28905
Guard Screw (3)*
12.
SZ79
End Roller Bearing Shaft
13.
SZ109
Moving Jaw End Beating Assembly
(Includes Figures 14-16)
14.
SZ32
Outer Race End Bearing
15.
SZ10
Needle Roller End Bearing (40)*
16.
SZ29
Inner Race End Bearing
17.
SZ03
Roller Shaft
18.
SZ107
Plate Roller Assembly (2)*
(Includes Figures 18-20)
19.
SZ97
Thrust Washer (4)*
20.
SZ31
Stationary Roller Plate (2)*
21.
SZ09
Needle Roller (20)*
22.
SZ74
Bearing Bolt
23.
SZ75
Bearing Bolt Nut
24.
SZ76
Bearing Bolt Washer
25.
SZ60
Tru-Arc Retainer Ring (2)*
26.
SZ54
Roller Shaft
27.
SZ02901
Cylinder
28.
SZ90
Wedge
29.
SZ117
Piston Return Spring (2)*
30.
SZ38
Wedge Spacer Rivet
31.
SZ08
Piston Fork
32.
SZ36
Piston
33.
SZ35
Piston Leather (3)*
34.
SZ34
Piston Leather Plate (3)*
35.
SZ89
Piston Rod
36.
SZ19
“O” Ring (2)*
37.
SZ44
Retaining Ring (4)*
38.
SZ40
Seperator (2)*
39.
SZ20
“O” Ring (2)*
40.
SZ50
Tandem Piston (2)*
41.
SZ51
Piston Rod
42.
SZ33
Piston Rod Nut
43.
SZ46
Cylinder Head Gasket
44.
SZE1071
Button Head Cap Screw (2)*
45.
SZE1068
Throttle Guard
46.
SZ47
Allen Cap Screw (4)*
47.
SZ98
Spring
48.
SZ102
Lever Arm Assembly
49.
SZ49
Screw
50.
SZ48
Lever Arm
51.
SZ57
Throttle Valve
52.
SZ58
“O” Ring
53.
SZ71
Throttle Valve Spring
54.
SZ81
“O” Ring (Brass Bushing)
55.
SZ55
Throttle Valve Bushing
56.
SZ56
Cylinder Head
57.
SZ122
Swivel Assembly
(Includes Figures 57-61)
58.
SZ95
Swivel Nut
59.
SZ93
“O” Ring (Swivel)
60.
SZ92
Swivel
61.
SZ94
“O” Ring
62.
SZ96
Elbow
NOTE
Due to very high squeezing pressures developed by this
tool, use Alligator Jaws equipped with heavy duty bearings
only. The use of standard bearings will cause damage to
the tool and possible injury to the operator
