2
GENERAL OPERATION
Reversing tools have a button to depress to reverse the air motor. Always depress the button fully to obtain full power.
The reversing button can be locked in the reverse direction by fully depressing and rotating the button clockwise.
TORQUE CONTROL CLUTCH OPERATION
Torque control tools will shut off when the preset torque is reached on the fastener. The tool will reset for the next cycle when
removed from the fastener.
Torque control clutches are adjusted externally with the use of Sioux No. 2366 clutch adjustment wrench or a #1 (3/16", 4.8mm
Dia. shank) Phillips screwdriver. Clutch adjustment is accomplished by rotating the clutch cover until the slot in the clutch case
appears. Turn the output spindle of the tool with a 1/4 (6.4mm) hex key wrench until the groove in the adjusting washer is aligned
with the slot in the clutch case. Insert the clutch adjustment wrench into the groove and push to fully engage the teeth. Turn the
clutch adjustment wrench counterclockwise to increase the torque.
Three clutch springs are available and are color coded for torque range.
#66050 green spring 2-20 in-lb (.23-2.26 N . m)
#66049 blue spring 15-35 in-lb (1.7-4 N . m)
#66048 silver spring 30-50 in-lb (3.39-5.6 N . m)
DECLARATION OF CONFORMITY
We, Sioux Tools Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declare under our sole responsibility that the products
1OT1108, 1OT1208, 1OT1308, 1OT1508, 1OT2108, 1OT2208, 1OT2308, 1OT2508, 1ST1108, 1ST1208, 1ST1308, 1ST1508, 1ST2108,
1ST2208, 1ST2308, 1ST2508, Includes products with ‘Y’ in the catalog number
to which this declaration relates are in conformity with the following standard or standards or other normative document or documents:
EN 792 (draft), EN 292 Parts 1&2, ISO 8662, Pneurop PN8NTC1
following the provisions of
89/392/EEC as amended by 91/368/EEC & 93/44/EC Directives.
June 1, 2003
Murphy, North Carolina, USA
Date and place of issues
Gerald E. Seebeck
President
Sioux Tools Inc.
Name and position of issuer Signature of issuer
