Sioux Tools PUSH TO START TOOLS - Manual

1
Form ZCE427A
Date 2006April28/G
Page 1 of 20
Printed In U.S.A.
INSTRUCTIONS & PARTS LIST FOR NO. 1 SERIES
“1ST” and “1OT” PUSH TO START TOOLS
SERIAL “C”
Read and understand "Safety Instructions For Air Tools" and these instructions before
operating this tool.
AIR SUPPLY
The efficiency of the tool is dependent on the proper supply of clean dry air at 90 psig (6.2 bar). The use of a line filter,
pressure regulator, and lubricator will insure maximum output and service life of tools.
HOSE AND HOSE CONNECTIONS
Supply hose should be not less than 3/8" (10mm) I.D. Extension hoses should be at least 3/8" (10mm) I.D. Use couplings and
fittings with at least 1/4" (6.4mm) I.D.
LUBRICATION
An airline lubricator, set to deliver one drop per minute, is recommended. If a lubricator is not used, add .04 oz. (1.2cc, 12 to
15 drops) of SIOUX No. 288 air motor oil into the air inlet daily.
Lubricate the gearing every 150 hours of operation with SIOUX No. 1232A grease. Lubricate positive clutch every 25 to 50
hours with SIOUX No. 1232A grease. Lubricate torque control clutches every 25 to 50 hours with light oil.
Tools left connected to the air supply while making adjustments, changing accessories, or doing any maintenance or service on tool can
start unexpectedly.
Always remove tool from air supply and activate trigger to bleed air line before making any adjustments, changing accessories,
or doing any maintenance or service on tool.
Tools starting unexpectedly can cause injury.
Catalog No. *Sound Pressure dBA *Sound Power dBA *Vibration m/s 2
1OT1108, 1OTY1108 73.9 85.23 Less than 2.50
1OT1208, 1OTY1208 73.9 85.23 Less than 2.50
1OT1308, 1OTY1308 73.9 85.23 Less than 2.50
1OT1508, 1OTY1508 73.9 85.23 Less than 2.50
1OT2108, 1OTY2108 73.18 85.11 2.95
1OT2208, 1OTY2208 73.18 85.11 2.95
1OT2308, 1OTY2308 73.18 85.11 2.95
1OT2508, 1OTY2508 73.18 85.11 2.95
1ST1108, 1STY1108 72.26 83.68 13.21
1ST1208, 1STY1208 72.26 83.68 13.21
1ST1308, 1STY1308 72.26 83.68 13.21
1ST1508, 1STY1508 72.26 83.68 13.21
1ST2108, 1STY2108 71.46 82.88 13.7
1ST2208, 1STY2208 71.46 82.88 13.7
1ST2308, 1STY2308 71.46 82.88 13.7
1ST2508, 1STY2508 71.46 82.88 13.7
*per PN8NTC1 *per PN8NTC1 *per ISO 8662
SOUND AND VIBRATION READINGS
