39. 65801 Vane (Set of 3)
40. 65661 Bearing—Support
65660 Bearing—Support (Front Exhaust Only)
41. 65662 Retainer—Motor
65800 Retainer—Motor (Front Exhaust Only)
42. 65659 Deflector
43. 21098 Body—Collet
44. 44440 Collet (1/4")
44523 Collet (3/16")
44522 Collet (1/8")
66037 Collet (3mm)
66038 Collet (6mm)
45. 21097 Nut—Collet
46. 43343 Chuck—1/4" (Complete Collet)
43344 Chuck—3/16"( Complete Collet)
43345 Chuck—1/8" (Complete Collet)
47. 21106 Body—Collet
48. 21100 Collet (1/4")
21101 Collet (3/16")
21102 Collet (1/8")
49. 21105 Nose Piece
50. 21104 Nut—Collet
51. 43351 Chuck—1/4" (Complete Collet)
43350 Chuck—3/16" (Complete Collet)
43349 Chuck—1/8" (Complete Collet)
52. 1359 Hose—Leader
53. 65628 Assy—Housing Venturi Vacuum
(Includes Figs 10, 11, 16, 25 & 27)
54. 65725 Connector
55. 65726 Hose—Adjustable (5-1/2" Long)
56. 65727 Nozzle
57. 855 Hose—Exhaust (3/4" x 6')
58. 65768 Outer Bag
59. 65776 Washer—Retainer
60. 912 Filter Bag (5 Pack)
61. 65771 Clip
62. 911A Assy—Disposable Dust Bag
63. 65873 Protector—Thread
Items Not Shown
30465 Wrench—9/16"
30466 Wrench—11/16"
65505 Cable Tie (Pack of 4)(Venturi Vacuum Only)
1. 65723 Hose—Exhaust (3/4" x 4')
2. 65654 Adaptor—Exhaust
3. 1359 Hose—Leader
4. 21541 Ring—Retaining
5. 30463 Screen
6. 14311 Ring—“O”
7. 65655 Adaptor—Inlet
8. 35289 Washer
9. 65675 Pad—Silencer
10. 65652 Nameplate
11. 09954 Drive Screw (2)*
12. 65626 Assy—Front Exhaust Housing
(Includes Figs 10, 11, 16, 21, 25 & 27)
65627 Assy—Rear And Remote Exhaust Housing
(Includes Figs 10, 11, 16, 21, 25 & 27)
13. 06099 Screw (#4–40 x 1/4)(2)*
14. 65669 Assy—Lever Lock
15. 35235 Lever
16. 06678 Screw (#8–32 x 3/16")
(Not Used With Twist Throttle)
17. 65779 Screw—Set (#8–32 x 3/8")
18. 65777 Valve—Twist
19. 65778 Support—Twist Valve
20. 14291 Ring—“O”
21. 65657 Valve—Speed Control
22. 21429 Spring
23. 14350 Valve
24. 25957 Washer
25. 65799 Assy—Plunger Valve
26. 14394 Ring—“O” (2)*
27. 65656 Body—Valve
28. 65688 Sleeve
65700 Sleeve (Lever Lock Only)
29. 65593 Assy—Motor
30. 21529 Ring—Retaining
31. 10255 Bearing—Ball
32. 65598 End Plate—Upper
33. 30273 Pin—Roll (2)*
34. 65599 Cylinder
35. 65601 Rotor
36. 44516 Spacer
37. 65638 End Plate—Front
38. 10259 Bearing—Ball
Fig. Part Name
No. No.
Fig. Part Name
No. No.
Remote Exhaust
*Order Quantity As Required
Rear Exhaust Only
Not Used On
Venturi Model
PARTS LIST FOR “1DS” SERIES STRAIGHT DIE GRINDERS
Erickson Collet
Sioux Collet
