PARTS LIST
REMOTE CONTROL LOG BASE ASSEMBLY
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 40 of this manual.
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
CGEFP33PRB CGEFP33NRB
1
111625-04
111625-04
Back Log (#2)
1
2
111625-03
111625-03
Middle Log (#1)
1
3
111625-02
111625-02
Front Log (#3)
1
4
111625-06
111625-06
Left Crossover Log (#4)
1
5
111625-08
111625-08
Right Crossover Log (#5)
1
6
104286-02
104285-02
ODS Pilot
1
098249-01
098249-01
ODS Nut
2
8
09938-05
09938-05
Pilot Tube
1
9
10193-02
111331-1
Inlet Tube
1
10
1052-04
1052-04
Burner Outlet Tube
1
11
111124-01
111124-01
Burner Retainer Spring
1
12
099056-19
099056-26
Burner Orifice Injector
1
13
1022-01
1022-01
Burner
1
14
M10908-2
M10908-2
Screw, Self-Tapping
2
15
**
**
Painted Base Assy
1
16
**
**
Firebox Bottom
1
1
1053-01
1053-01
Valve Bracket
1
18
10559-02
10559-01
Gas Control Valve
1
19
102445-01
102445-01
Piezo Ignitor
1
20
102334-01
102334-01
Palnut Fastener
1
21
10562-01
10562-01
Switch and Wire Assembly
1
22
10685-01
10685-01
Bracket, Switch and Piezo
1
23
101628-03
101628-03
Flexible Connector
1
24
098544-01
098544-01
Wire Support Clip
1
25
099415-18
099415-12
Pressure Regulator
1
26
09809-03
09809-03
Fitting 3/8" Flare to 1/2" NPT
1
2
1068-01
1068-01
Electrode Bracket
1
28
103904-02
103904-02
Electrode
1
29
100694-01
100694-01
Screw, #6 x 1 1/4" PH
2
30
10560-01
10560-01
Magnetic Manual Override Handle
1
31
10563-01
10563-01
Wall Switch and Cord
1
32
10558-01
10558-01
Wall Switch Decorative Plate
1
33
102349-02
102349-02
Support, PCB
4
34
10561-01
10561-01
Wall Plate Decal
1
35
10564-01
10564-01
Remote Control
1
36
10565-01
10565-01
Receiver Assembly
1
3
10565-02
10565-02
Sensor Assembly
1
38
10566-01
10566-01
Module, Control Board
1
39
09821-08
09821-08
Ignitor Cable
1
40
10568-01
10568-01
Main Power Cable
1
41
104015-01
104015-01
Power Cord
1
42
101629-01
101629-01
1.5" Bushing
2
43
098303-02
098303-02
Screw, #6
2
44
1043-01
1043-01
Thermocouple Wire
1
45
1084-01
1084-01
Screw, #6019 x 1/4"
2
46
1039-02
1039-02
Plug, Button 3/4"
1
4
1039-01
1039-01
Plug, Button 5/8"
1
PARTS AVAILABLE — NOT SHOWN
1924000
1924000
Cable Tie
4
901056-01
901056-01
Fitting, 3/8" NPT
1
1036-01
1036-01
Wall Plate Assembly Kit (Contains
Items 32, 34, 45)
1
103-01
103-01
Wall Switch Assembly Kit (Contains
Items 29, 31, 32, 34, 45)
1
** Not a field replaceable part.
